ATX power supply 420W Akyga AK-B1-420 P4 3x SATA 2x Molex PPFC FAN 12cm
- Product code AK-B1-420
- Product typeComputer power supply
- FormatATX 2.31
- SeriesBasic
- Supply voltage230 V
- Power consumption< 5 A
- Efficiency> 70 %
- 80 PLUS compatibilityNo
- 80 PLUS certificateNone
- Current on the +3.3V rail24 A
- Current on the +5V rail 28 A
- Maximum load on +3.3V and +5V line210 W
- Current on the +12V rail19 A
- Maximum load on 12V line228 W
- Maximum power420 W
- Mainboard Power Connector24-pin
- Power connector ATX12V P41 pc
- Power connector EPS12V 8 pin None
- Power connector PCI-E 6 pin None
- Power connector PCI-E 6+2 pin None
- Power connector PCI-E 8 pin None
- Molex connector2 pcs
- Mini-Molex connectorNone
- SATA connector3 pcs
- Modular power supplyNo
- PFC filterPassive
- Mechanical switchYes
- Ground wireYes
- OVPYes
- OCPYes
- OPPYes
- OTPYes
- SCP Yes
- UVPNone
- Power supply connectorIEC C14
- Fan size120 mm
- Cable length30 - 60 cm
- Power cable included No
- MaterialGalvanized steel
- Product colorGrey
- MTBF100000 h
- Temperature5 - 50 °C
- PackageFoil
- Product size (L x W x H)140 x 150 x 85 mm
- Package size (L x W x H)196 x 151 x 86 mm
- Net weight1.04 kg
- Gross weight1.05 kg
- CE compatibilityYes
- FCC compatibilityNo
- RoHS compatibilityYes
- REACH compatibilityYes
- EAN code5901720130310
- Warranty24 months
Akyga® AK-B1-420 ATX power supply 420W is one of the basic power supplies in our offer dedicated to power desktop computers.
Made of high quality components, the power supply has a 3 SATA connectors, 2 MOLEX connectors, P4 4-pin connector and a universal 24-pin motherboard connector. Supports ATX 12V 2.0 specifications, so it can be used with current and next generation of platforms with multi-core processors. Silent 12 cm fan with chromed grill provide efficient cooling. Manual on/off switch allows for safe power cut off without the need of disconnecting the network cord. High efficiency and stable operation of the power supply affects the reliability of all computer components.
Several important protectors (OVP, OCP, OPP, OTP, SCP) and PFC filter protect and prevent main computer parts from damage and stabilize the operation of the power supply so that it works without any unwanted interference.
